Dual dash cam Front and inside
Dual dash cam Front and inside V5
The YUWEI 'V5' dual dash cam is the perfect solution for your car, providing front and inside recording with infrared night vision. It features 1080P recording and HDR technology, ensuring clear and detailed images and video capture. The dash cam also allows for simultaneous audio recording of both the interior and rear of the vehicle, making it ideal for capturing clear and detailed video evidence in the event of accidents.
The V5 dash cam also integrates built-in advanced driver-assistance systems (ADAS, DSM) to enhance safety. It supports up to 4 camera channels, providing real-time audio and video recording, and is widely used in areas such as ride-hailing, taxis, logistics, and official vehicles.
Another important feature of the dual dash cam is loop recording, allowing continuous recording of the surrounding environment. It automatically deletes the oldest stored videos to free up space for recording the latest footage when the memory is full.
Equipped with a G-sensor, the dash cam can detect accidents and has a parking mode that allows recording while the vehicle is parked, capturing the surroundings. It is easy to install on the windshield without any complicated settings and can also record video with the screen turned off.
Below are the specifications for the front and inside dash cam
Parameter classification | Parameter item | Details |
Basic parameters | Appearance | device integrate with ADAS cam |
Product Type | 4G DVR Car Video Terminal | |
network standard | 4G Global Band | |
Memory | 256MB(Flash)+1GB(DDR) | |
Front camera (ADAS Camera) | 1080P, MIPI Camera, H:112°V:55° | |
In-car camera | AHD 720P, with light sensor/infrared night vision, | |
AHD Camera, single pass, infrared night vision, H=60° V=42° | ||
4th Channel camera | AHD 720P | |
Hardware function
| GPS | Support: GPS+BDS |
Wi-Fi | 802.11b/g/n | |
trumpet | 8 ohms 1.5 watts, 1 channel, with sound cavity | |
MIC | Built-in dual silicon microphone design | |
Accelerometer | 3-axis accelerometer | |
Interface | micro 5Pin USB | USB×1, data interface |
BMW connector | Power+/GND ACC Left turning signal cable Right turning signal cable SOS Cable (Panic button) | |
RS232 | 1*RS232 | |
SIM card holder | Micro SIM | |
TF card holder | TF×2 (Card 1 and Card 2 support circular storage) | |
Power supply | Power supply | 12V/24V power supply |
Button& Indicator light
| Reset button | Long press the power button for 8 seconds to reset |
indicator light | 2-color indicator | |
Alarm key | Standard emergency alarm connector | |
Antenna
| GPS Antenna | Built-in ceramic antenna |
4G antenna | Built-in FPC+IPEX transposon | |
WIFI antenna | Built-in FPC+IPEX transposon | |
Memory card | 4G～2TB, patented DXR streaming storage format | |
Electrical Specification | Operating temp. | -20℃～70℃ |
Storage temp. | -40℃～85℃ | |
Static Protection | 6KV contact, 10KV air | |
Vibration test | Car vibration | |
Current consumption | When the working voltage is 12V, the current is from 500mA to 1A (depending on whether the algorithm is turned on, etc.) When ACC OFF: ≤3mA | |
Other quality requirements | According to JT/T794 standard (including hard test, soft test, reliability, quality, etc.) | |
Dual dash cam Front and inside specification chart
l Red light
Equipment situation | Light status |
Before the program is ready | Solid on |
during upgrade | On for 1 second, off for 4 seconds |
update completed | |
camera lost | On for 0.1 seconds, off for 0.1 seconds, flashing 4 times at a time, flashing once every 4 seconds |
SIM card missed | On for 1 second, off for 1 second |
other status | Always off |
l Green light
Equipment situation | light status |
Before the program is ready | Solid on |
during upgrade | On for 1 second, off for 4 seconds |
update completed | |
The card is recording normally | On for 1 second, off for 1 second |
Unrecorded card abnormal | On for 0.1 seconds, off for 0.1 seconds, flashing 4 times at a time, flashing once every 4 seconds |
other status | Always bright |
TF card/SIM card/USB location
