Multi Camera Dash Cam System

Date Time: March 07, 2024

Reading volume: 105

Author: ROYIS

Multi Camera Dash Cam System Supplier

V5 is a high-cost-performance multi-channel dash cam integrating positioning, 2G/3G/4G communication, and remote vehicle monitoring. It is equipped with built-in GPS/BD positioning module, 4G module, WIFI module, audio and video encoding/decoding SOC, supporting 4 channels of video, 2 channels of audio, dual TF card, and video recording storage functions.

Multi Camera Dash Cam System

Multi Camera Dash Cam Features

1 channel of 1080P and 3 channels of 720P high-definition video

Loop recording

Collision lock/wake-up

Emergency alarm

Remote real-time positioning and trajectory playback

Voice intercom

Remote real-time video and playback

Advanced Driver Assistance System (ADAS) + Driver Behavior Monitoring (DSM)

Multi Camera Dash Cam

Multi Camera Dash Cam Specification

Parameter classification	Parameter item	Details
Basic parameters	Appearance	device integrate with ADAS cam
	Product Type	4G DVR Car Video Terminal
	network standard	4G Global Band
	Memory	256MB(Flash)+1GB(DDR)
	Front camera (ADAS Camera)	1080P, MIPI Camera, H:112°V:55°
	In-car camera	AHD 720P, with light sensor/infrared night vision,
	DSM camera	AHD Camera, single pass, infrared night vision, H=60° V=42°
	4th Channel camera	AHD 720P
Hardware function	GPS	Support: GPS+BDS
	Wi-Fi	802.11b/g/n
	trumpet	8 ohms 1.5 watts, 1 channel, with sound cavity
	MIC	Built-in dual silicon microphone design
	Accelerometer	3-axis accelerometer
Interface	micro 5Pin USB	USB×1, data interface
	BMW connector	Power+/GND ACC Left turning signal cable Right turning signal cable SOS Cable (Panic button)
	RS232	1*RS232
	SIM card holder	Micro SIM
	TF card holder	TF×2 (Card 1 and Card 2 support circular storage)
Power supply	Power supply	12V/24V power supply
Button& Indicator light	Reset button	Long press the power button for 8 seconds to reset
	indicator light	2-color indicator
	Alarm key	Standard emergency alarm connector
Antenna	GPS Antenna	Built-in ceramic antenna
	4G antenna	Built-in FPC+IPEX transposon
	WIFI antenna	Built-in FPC+IPEX transposon
Memory card	4G～2TB, patented DXR streaming storage format
Electrical Specification	Operating temp.	-20℃～70℃
	Storage temp.	-40℃～85℃
	Static Protection	6KV contact, 10KV air
	Vibration test	Car vibration
	Current consumption	When the working voltage is 12V, the current is from 500mA to 1A (depending on whether the algorithm is turned on, etc.) When ACC OFF: ≤3mA
	Other quality requirements	According to JT/T794 standard (including hard test, soft test, reliability, quality, etc.)
